Free Renewable Green Energy 48V 96V 50AH 200AH UPS Lithium Power
Storage System With Multi Certification For Home Use
Jiangsu Shenghuang New Energy Technology Co..Ltd. is located in
Wuxi Liangxi district Jinshan North science and Technology
Industrial Park, is a factory commitment to wind generators, solar
monitoring system, wind and solar complementary monitoring system,
photovoltaic system, wind and solar complementary
controller,inverter,Gel battery, Lithium Battery Development and
integrated application of green energy saving and environmental
protection technology enterprises.
Lithium-ion batteries are currently the most popular battery
storage option, controlling more than 90% of the global grid
battery storage market. Lithium-ion batteries offer high energy
density and light weight compared to other battery options. New
innovations, such as replacing graphite with silicon to increase
the power capacity of batteries, are seeking to make lithium-ion
batteries more competitive for long-term storage.
In addition, lithium-ion batteries are now routinely used in rural
electrification in developing countries. In rural communities,
lithium-ion batteries are paired with solar panels, enabling homes
and businesses to use limited amounts of power to charge phones,
run appliances and light buildings. Previously, these communities
had to rely on dirty and expensive diesel generators, or had no
access to electricity.
STEP 1: CHARGE
The battery storage system is charged by clean electricity
generated by solar or wind turbine.
STEP 2: DISCHARGE
Energy is discharged from the battery storage system during times
of high usage, reducing or eliminating demand charges.
| Powerwall LiFePO4 Battery(48V 200Ah) |
| Technical Parameter |
| NO | Item | Parameters |
| 1.Performance | Type | LiFePO4 battery(CELL:3.2V100Ah) |
| Nominal Voltage | 51.2V |
| Rated Capacity | 200Ah(0.2℃/25℃)(Min:198Ah) |
| Operating Voltage Range | 42V-57.0V(Typical 51.2V) |
| Charging Voltage | 57.0V |
| Discharge Cut-off Voltage | 42V |
| Charging Current(Max.) | 60A |
| Discharge Current(Max.) | 100A |
| Width | 435mm |
| Height | 875mm |
| Depth | 190mm |
| Weight | 102Kg |
| 2.Function | Installation Method | |
| Communication | RS485 |
| Terminal Stud | M8 Bolt |
| Alarm&Protection | Over Voltage,under Voltage,short circuit,over current,over
temperature,low temperature protection etc. |
| 3.Working Condition | Cooling Mode | Automatic Cold and hot |
| Altitude | ≤4000m |
| Humidity | 15%-85% |
| Operating Temperature | Charge 0℃-45℃ Discharge -10℃-60℃ |
| Recommended Charge Temperature | 15℃-40℃ |
| Recommended Discharge Temperature | 15℃-40℃ |
| Recommended Storage Temperature | 0℃-35℃ |
Product Feature
1. Lithium Ion Battery For Energy Storage
2. Rechargable
3. Over-charge,over-discharge and overload protections for
batteries
4. Compatible with energy storage system
5. CE Certification
6. WIFI or Bluetooth communication is optional
Battery energy storage systems are rechargeable battery systems
that store energy from solar arrays or wind turbine or the electric
grid and provide that energy to a home or business. Because they
contain advanced technology that regular batteries do not, they can
easily perform certain tasks that used to be difficult or
impossible.
The idea of combining solar panels and batteries is not new. Early
solar pioneers often attached a series of oceanic deep cycle
batteries to their solar arrays. Before net metering became
commonplace, this was the only way to use stored solar energy at
night. Modern battery energy storage systems are conceptually
similar but more complex and powerful. If those old battery arrays
were like flip phones, modern battery energy storage systems are
like the latest smartphones—they have the same main functions, but
everything else is worlds apart.
Modern battery energy storage systems often include built-in
inverters and computer control systems. This means they are
all-in-one turnkey systems that are simple to install, essentially
maintenance-free, and require no effort or expertise from the
owner. They are also weatherproof and safe for people and pets.
Q&A
Q1 Is there an endless supply of lithium?
A1 The world's reserves of lithium is estimated at 38 million
metric tons. So, there is probably enough lithium reserves to meet
electric car batter needs for some time.
Q2. What is the advantage of Lithium Ion Phosphate Battery?
A2. Lithium iron phosphate batteries (LiFePO4 or LFP) have many
advantages over lead-acid batteries and other lithium batteries.
Longer life, maintenance free, extremely safe, light weight,
improved discharge and charge efficiency, to name a few. LiFePO4
batteries aren't the cheapest on the market, but with their long
life and zero maintenance, it's the best investment you can make in
a while.
Q3. What system do you want, on-grid or off-grid?
A3. Both
Q4. Can I get the entire Wind and Solar system from there?
A4. Of course. Jiangsu Shenghuang New Energy Technology Co., Ltd.
can provide energy solutions for the elderly. Have our own
technical team to provide technical support. You just have to ask a
technician to install it for you.
Q5. Can Lithium Batteries Power a House?
A8. A home needs several lithium-ion batteries to power it for a
day or more. Lead-acid batteries have been around for decades, are
less efficient, offer less storage space, are usually larger, and
don't last as long. Lithium batteries can be partially charged
without any adverse effects.
Q6. Are lithium-ion solar cells the best energy storage option?
A4:Lithium-ion solar cells are the best solar energy storage
systems for everyday residential use because they take up little
space but still store a lot of energy. Plus, their high mod means
you can use more energy storage.
